產品介紹
| Fan = DC-Fan | Size = 92x92x32 | Speed = | Flow = | Noise = |
| Bearing type: ◎=Ball ※=Sleeve ●=Hypro Bearing | |||||||||
| Frame Size | Model No | Bearing | Volt. (VAC) | Current (A) | Speed (rpm) | Air Flow (CFM) | Pressure (InAq) | Noise (dB/A) | |
| 92x92x32(gl-n) | AD0912LB-Y73GL(N) | ◎ | 12 | 0.16 | 2500 | 48.046 | 0.142 | 34.7 |  |
| 92x92x32(gl-n) | AD0912MB-Y73GL(N) | ◎ | 12 | 0.24 | 3000 | 58.973 | 0.189 | 39.5 | |
| 92x92x32(gl-n) | AD0912HB-Y73GL(N) | ◎ | 12 | 0.38 | 3500 | 68.954 | 0.284 | 44.0 | |
| 92x92x32(gl-n) | AD0912UB-Y73GL(N) | ◎ | 12 | 0.45 | 3900 | 77.186 | 0.371 | 50.0 | |
| 92x92x32(gl-n) | AD0924LB-Y73GL(N) | ◎ | 24 | 0.08 | 2500 | 48.046 | 0.142 | 34.7 | |
| 92x92x32(gl-n) | AD0924MB-Y73GL(N) | ◎ | 24 | 0.14 | 3000 | 58.973 | 0.189 | 39.5 | |
| 92x92x32(gl-n) | AD0924HB-Y73GL(N) | ◎ | 24 | 0.21 | 3500 | 68.954 | 0.284 | 44.0 | |
| 92x92x32(gl-n) | AD0924UB-Y73GL(N) | ◎ | 24 | 0.24 | 3900 | 77.186 | 0.371 | 50.0 | |
| 92x92x32(gl-n) | AD0948LB-Y73GL(N) | ◎ | 48 | 0.06 | 2500 | 48.046 | 0.142 | 34.7 | |
| 92x92x32(gl-n) | AD0948MB-Y73GL(N) | ◎ | 48 | 0.08 | 3000 | 58.973 | 0.189 | 39.5 | |
| 92x92x32(gl-n) | AD0948HB-Y73GL(N) | ◎ | 48 | 0.10 | 3500 | 68.954 | 0.284 | 44.0 | |
| 92x92x32(gl-n) | AD0948UB-Y73GL(N) | ◎ | 48 | 0.13 | 3900 | 77.186 | 0.371 | 50.0 | |
Note：
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規(guī)電流值；若有進一步需求，請直接與浩禧業(yè)務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規(guī)電流值；若有進一步需求，請直接與浩禧業(yè)務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
